The New LAUDA PRO: Compact, Efficient, Powerful.

The PRO heating circulation thermostats are designed for external applications up to 250°C. The low filling volume permits rapid heating up in the connected application. The compact construction permits space-saving installation of the thermostats. An integrated cooling coil, fitted as standard, provides cooling.

The PRO cooling circulation thermostats are ideal for external applications where rapid temperature changes are required. The cooling output of 0.6 and 0.8 kW, combined with a very low filling volume permit these rapid temperature changes. The thermostats have a working temperature range of -40 to 200°C. All types are fitted with a pressure-suction pump. Hybrid cooling of the refrigerating machine permits cooling using ambient air or, in addition, using cooling water.

Available Models

Technical Specifications

Working temperature min.80°C
Working temperature max.250°C
InterfaceEthernet, USB (Type B)
Temperature stability0.05 ±K
Bath volume max.4.4 L
Heater power2.5 kW

Technical Specifications

Working temperature min.-40°C
Working temperature max.200°C
InterfaceEthernet, USB (Type B)
Temperature stability0.05 ±K
Bath volume max.4.4 L
Heater power2.5 kW

Technical Specifications

Working temperature min.-45°C
Working temperature max.200°C
InterfaceEthernet, USB (Type B)
Temperature stability0.05 ±K
Bath volume max.4.4 L
Heater power2.5 kW

Technical Specifications

Working temperature min.-50°C
Working temperature max.200°C
InterfaceEthernet, USB (Type B)
Temperature stability0.05 ±K
Bath volume max.4.4 L
Heater power2.5 kW

Technical Specifications

Working temperature min.-90°C
Working temperature max.200°C
InterfaceEthernet, USB (Type B)
Temperature stability0.05 ±K
Bath volume max.4.4 L
Heater power2.5 kW

Key Features

100% flexibility for internal temperature control

  • Functional check of electronic components
  • Material testing of metal and plastic samples
  • Sensor calibration
  • Temperature control of measuring cells

100% efficiency for external applications

  • Thermal control of chemical and biological reactions
  • Precise temperature control for crystallization processes
  • Temperature control of measuring and testing rigs, heat exchangers and distillation plant

Key Industries

  • Aerospace
  • Agriculture
  • Automotive
  • Biopharmaceutical and Biotechnology
  • Chemical
  • Construction
  • Cosmetics & Personal Care
  • Defense
  • Die & Mould
  • Education & Academics
  • Electronics
  • Energy
  • Environmental
  • Food & Beverage
  • Luxury
  • Machinery & Manufacturing
  • Medical
  • Mining & Minerals
  • Oil & Gas
  • Optical
  • Paper & Wood
  • Pharmaceutical
  • Polymers, Plastics and Rubbers
  • Powders & Pigments / Coating
  • Railway
  • Semiconductor, Solar & Electronics
  • Service
  • Textile
  • Wholesale & Retail

Brand

Lauda

We are LAUDA – The world leader in precise temperature control. Our Constant temperature equipment and Heating and cooling systems are at the heart of many applications. As a full-service provider we guarantee the optimum temperature in research, production and quality control. We are the trusted partner, particularly in the fields of automotive, chemical/ pharmaceutical, semiconductor and laboratory/ medical industries. For over 60 years we have been inspiring our customers with our competent consulting and innovative, environmentally-friendly concepts, anew every day – globally.
